Dual Channel Handheld Digital Storage Oscilloscope HO104
Description
| Product Technical Parameters | ||
| Model Number | HO1104 | |
| Bandwidths | 110MHZ | |
| (communications) channel | quad | |
| real time sampling rate | 500 MS/s *2 | |
| sampling mode | Normal sampling, peak detection, averaging | |
| Storage depth | 20K | |
| importation | Input coupling | DC, AC, Ground |
| Input Impedance | 1 MΩ ± 2% in parallel with 20 pF ± 10 pF | |
| Probe attenuation coefficient | 1X，10X，100X，1000X | |
| Maximum Input Voltage | 400 V (DC + AC peak) | |
| Isolation between channels | 50 Hz: 100 : 1 | |
| 0 MHz: 40 : 1 | ||
| Interchannel time delay (typical) | 150 ps | |
| bandwidth limit | 20 MHz, full bandwidth | |
| 水平 | Sample rate range | 0.5 S/s～1 GS/s |
| Waveform interpolation | (sinx)/x | |
| Maximum storage depth | 20K | |
| Sweep speed range (S/div) | 2 ns/div～1000 s/div | |
| Steps in 1 to 2 to 5 decimal system. | ||
| time base accuracy | ±100 ppm | |
| Time interval (ΔT) measurement accuracy (DC to 100MHz) | Single: ± (1 sample interval + 100 ppm x reading + 0.6 ns) | |
| >16 averages: ±(1 sample interval + 100 ppm x reading + 0.4 ns) | ||
| 垂直 | Analogue to digital converter (A/D) | 8-bit resolution, two channels sampled simultaneously. |
| Sensitivity (volts/gram) range | 5 mV/div～5 V/div | |
| displacement range | ±2 V (5 mV/div – 200 mV/div) | |
| ±100 V (500 mV/div – 5 V/div) | ||
| analogue bandwidth | 110 MHz | |
| unit bandwidth | full bandwidth | |
| Low Frequency Response (AC coupling, -3dB) | ≥10Hz (on BNC) | |
| Rise time (typical on BNC) | ≤ 3.5 ns | |
| DC Gain Accuracy | ±3% | |
| DC measurement accuracy (average value) | The voltage difference (ΔV) between any two points on the waveform after averaging ≥16 captured waveforms: | |
| (Sampling mode) | ± (3% of reading + 0.05 cells). | |
| Enable/disable waveform inversion | ||
| surveying | cursor measurement | Voltage difference between cursors (△V), time difference between cursors (△T) |
| Automatic measurement | Period, Frequency, Average, Peak, Root Mean Square, Maximum, Minimum, Top, Bottom, Amplitude, Overshoot, Preshoot, Rise Time, Fall Time, Positive Pulse Width, Negative Pulse Width, Positive Duty Cycle, Negative Duty Cycle, Delay A->B, Delay A->B | |
| Root Mean Square, Vernier RMS, duty cycle, phase | ||
| mathematical operation | Addition, subtraction, multiplication, division, FFT | |
| Stored Waveforms | 16 Waveforms | |
| Stored Waveforms | full bandwidth | |
| communications interface | ||
| communications interface | USB 2.0, support USB stick storage | |
| frequency meter | adjuvant | |
