1)Voltage and current can be preset;
2)Power display
3)Unique front output on-off one-key switch control;
4)Turn on or off the external SETOUT function when power-on output;
5)LOCK lock function to prevent accidental touch;
6)Display the decimal point automatic carry function;
7)Low noise and low ripple;
8)High-quality coding switch control;
9)Powerful protection functions for over voltage, over current, over power and over temperature;
10)Mini size and lighter weight;
| Voltage | |
| Load regulation rate | ≤0.1%+5mV |
| Power regulation rate | ≤0.01%+5mV |
| Set resolution | 10mV |
| Setting accuracy | ≤0.1%±1 digits |
| Readback resolution | 10mV |
| Readback accuracy | ≤0.1%±1 digits |
| Ripple | 10mVrms |
| Electric current | |
| Load regulation rate | ≤0.2%+3mA |
| Power regulation rate | ≤0.2%+3mA |
| Set resolution | 1mA |
| Setting accuracy | ≤0.2%±3mA |
| Readback resolution | 1mA |
| Readback accuracy | ≤0.2%±3digits |
| Ripple | 8mVrms |
| OVP | Vmax+2V |
| Maximum voltage | Vmax±0.2% |
| OCP | Cmax+1A |
| Maximum current | Cmax±0.2% |
| Working conditions | Temperature 0~40℃ Relative humidity: ≤80%RH |
| Storage conditions | Temperature -20~60℃ Relative humidity: ≤80%RH |
| Cooling method | Wind cooling |
| Weight | 1.95KG |
Size(Bare metal) 80*150*230(MM)
